Moobody ATS-20 SI4735 Radio Receiver for Full Waveband AM MW SW SSB LSB USB Amateur Bands GDF_WK86252

$39.99  $7.29




Product details:

color:#FF0000;color:#FF0000;ATS-20 SI4735 Full Waveband Radio Receiver AM (MW & SW) SSB (LSB & USB) Covering Commercial Amateur Radio BandsThis is a kind of quality full waveband radio receiver, 0.96 inch OLED display, support auto-hold setting function after power failure. Equipped with audio output function, support 3.5mm earphone. Also support 4ohm speaker 2W output. With 22 commercial and amateur radio bands pre configured, you can use it freely. You can have a try.
Features:
0.96 inch OLED display, you can see band, AGC on/off, MONO according to your demands.
Support auto-hold setting function after power failure.
With built in 3.6V, 600mAH polymer   battery for stable and sustainable power supplys.
Support USB recharging, delivering with type-c recharging cable.
Equipped with audio output function, support 3.5mm earphone.
Also support 4ohm speaker 2W output.
Antenna interface uses SMA interface and printed circuit board retains SI4735 package, you can replace chip by yourselves, and software is compatible.
With 22 commercial and amateur radio bands pre configured, you can use it freely.
, AM (MW and SW) and SSB (LSB and USB).
Audio bandwidth filter 0.5, 1, 1.2, 2.2, 3 and 4Khz.
BFO Control.
Frequency step switch (1, 5 and 10KHz).
Specifications:
Name: Radio Receiver
Material: printed circuit board
Band:
{FM_BAND_TYPE, 8400, 10800, 10430, 10},
{LW_BAND_TYPE, 100, 510, 300, 1},
{MW_BAND_TYPE, 520, 1720, 810, 10},
{SW_BAND_TYPE, 1720, 3500, 1900, 1}, // 160 meters
{SW_BAND_TYPE, 3500, 4500, 3700, 1}, // 80 meters
{SW_BAND_TYPE, 4500, 5500, 4850, 5},
{SW_BAND_TYPE, 5500, 6300, 6000, 5},
{SW_BAND_TYPE, 6300, 7800, 7050, 5}, // 40 meters
{SW_BAND_TYPE, 7800, 10000, 9600, 5},
{SW_BAND_TYPE, 10000, 11000, 10100, 1}, // 30 meters
{SW_BAND_TYPE, 11000, 12500, 11940, 5},
{SW_BAND_TYPE, 12500, 13900, 13600, 5},
{SW_BAND_TYPE, 13900, 14500, 14270, 1}, // 20 meters
{SW_BAND_TYPE, 14500, 15900, 15300, 5},
{SW_BAND_TYPE, 15900, 17900, 17600, 5},
{SW_BAND_TYPE, 17900, 18300, 18100, 1},  // 17 meters
{SW_BAND_TYPE, 18300, 21900, 21200, 1},  // 15 meters
{SW_BAND_TYPE, 21900, 26200, 24940, 1},  // 12 meters
{SW_BAND_TYPE, 26200, 27900, 27500, 1},  // CB band (11 meters)
{SW_BAND_TYPE, 27900, 30000, 28400, 1}}; // 10 meters
Item size: 89 107 41mm / 3.50 4.21 1.61in
Item weight: 205g / 7.23ounce
Package size: 173 122 52mm / 6.81 4.80 2.05in
Package weight: 250g / 8.82ounce
Packing List:
1 Radio Receiver
1 Antenna
1 Type-C Cable
color:#FF0000;
Manufacturer Part Number:E19709
Brand:Moobody
